Case Studies
MedicalHeart Rate Variability Analyzer
High-reliability medical PCB for a portable heart rate variability analyzer requiring strict biomedical compliance, fine-pitch component placement, and impedance-controlled signal routing.
Power & EnergyConverter Valve Control & Monitoring System
Heavy copper PCB design for a high-voltage converter valve controller used in power transmission, featuring 4oz copper layers and thermal management for continuous high-current operation.
Industrial ControlEdge General-Purpose Computing Controller
Modular industrial edge controller PCB with security-hardened design, featuring high-speed signal routing for real-time data processing in factory automation environments.
AI & IoTAI Edge Computing Platform (Xavier EVK)
High-performance AI edge computing evaluation board with Jetson Xavier module, featuring 12-layer HDI PCB with fine-pitch BGA routing and advanced thermal management for AIoT applications.
MedicalPrecision Temperature Control Board
Medical-grade temperature control PCB with STM32 processor for precise heater and cooling management, featuring mixed SMT and THT assembly for robust clinical equipment deployment.
Telecommunications5G Communication Antenna Board
High-frequency 18-layer antenna PCB for 5G base stations using Rogers RO4350B and mixed dielectric stackup, with precision impedance control for mmWave signal performance.
Artificial IntelligenceIntelligent Patrol Robot Controller
Multi-sensor fusion controller PCB for an autonomous patrol robot, integrating RK3288 processor with triple-axis accelerometers, camera interfaces, and wireless communication modules.
Industrial ControlMulti-Axis Motion Control Card
FPGA-based multi-axis motion control card with Xilinx XC3S1200E and DSP module for CNC machinery, featuring precision analog output and encoder feedback interfaces.
Power & EnergyHigh Thermal Conductivity LED Driver PCB
Metal-core PCB with ceramic-filled substrate achieving 30+ W/mK thermal conductivity for high-power LED lighting drivers, enabling superior heat dissipation without external heatsinks.
AI & IoTHigh-Step HDI PCB with Staggered Vias
Advanced 10+ step HDI interconnect board with staggered microvia construction, 3/3 mil trace routing, and immersion gold finish for next-generation AIoT computing modules.
TelecommunicationsHandheld Mobile Encrypted WiFi Device
Compact wireless router PCB with hardware encryption for secure mobile networking, featuring RF-optimized 6-layer design with integrated antenna matching and power management.
Medical10-Layer Impedance-Controlled Medical Controller
High-speed 10-layer medical controller PCB with 4.5/4 mil trace routing and controlled impedance for diagnostic imaging equipment, manufactured to IPC Class 3 standards.
Data TransmissionHigh-Speed Data Transmission Module
ZYNQ7020-based data transmission PCB coordinating high-bandwidth command and telemetry links, with double-sided mixed assembly for military-grade communication systems.
AI & IoTRK3568 Entry-Level Edge AI Computing Board
Cost-optimized edge AI evaluation board based on Rockchip RK3568, featuring 8-layer PCB with high-speed memory and camera interfaces for smart retail and industrial vision applications.
